2.4 Inch IPS TFT LCD Display with 300 Nit Brightness 800:1 Contrast Ratio and -20~70℃ Operating Temperature

Pin : 14

Number Of Dots : 240（RGB）X 320

Product Type : Tft Lcd

Operation Temperature : -30℃ to +85℃

Outline Dimension : 42.72x60.26x3.05mm

Operating Temp : -20~70℃

Angle Of View : IPS All View Angle

Specification : ISO9001, ROHS

Place of Origin : China

Brand Name : BBI

Certification : ISO9001 RoHS

MOQ : 1000

Price : 0.7-7USD

Packaging Details : CARTON

Delivery Time : 3-4WEEKS

Payment Terms : T/T

Supply Ability : 100000/MONTH

Contact Now

2.4" IPS TFT LCD Display 240×320 Resolution SPI Interface with CTP

2.4 inch TFT LCD (Thin Film Transistor Liquid Crystal Display) is a small-size display module that uses TFT technology to provide high-quality color images and videos. The display has a diagonal screen size of 2.4 inches and a resolution of 240×320 pixels, providing clear and sharp images with accurate color representation.

Key Specifications

Resolution	2.4 Inch 240×320
Interface	4 Wire SPI
Driver IC	ST7789V
Brightness	300 Nit
Viewing Angle	IPS All View Angle
Display Area	36.72(H)×48.96(V)mm
Contrast Ratio	800:1

Detailed Technical Specifications

Screen Size	2.4 inch
Number of Pixels	240RGB(H)×320(V)
Display Area	36.72(H)×48.96(V)mm
Pixel Pitch	0.153(H)×0.153(V)mm
Pins	14 Pins
Outline Dimension	42.72×60.26×3.05mm
Pixel Arrangement	RGB Vertical Stripe
Display Mode	Normally Black
Viewing Direction	ALL
Display Color	262K
Luminance	300 nit
Interface	4Line SPI
Back-light	LED Side-light type
Drive IC	ST7789V
Operation Temperature	-20~70℃
Storage Temperature	-30~80℃

Product Features

IPS Technology: Features full-view characteristics with minimal color distortion from any angle
SPI Interface: Simple 4-wire connection with fast data transmission for easy microcontroller integration
Capacitive Touch Panel (CTP): Supports multi-touch with fast response and high accuracy
High Brightness: 300 nit brightness ensures visibility in various lighting conditions
Wide Temperature Range: Operates from -20℃ to 70℃ for diverse application environments
Compact Size: Small form factor (42.72×60.26×3.05mm) ideal for portable devices
